HWT Impregnated Hard Rock Casing Shoe Drill Bits For Exploration Core Drilling

1-5 pcs
MOQ
HWT Impregnated Hard Rock Casing Shoe Drill Bits For Exploration Core Drilling
विशेषताएं गेलरी उत्पाद विवरण एक बोली का अनुरोध
विशेषताएं
निर्दिष्टीकरण
Name: Rock Casing Shoe Drill Bits
Origin: China oil casing
China: China steve madden drill shoes
Sales: drill shoe buffer for sale
Bits: Diamond drill bits
Types: Types of drill bits
Use: concrete drill bits
Size: micro drill bits
Drilling Bits: China Diamond Casing Shoe Drilling Bits
Series: Wireline Diamond Core bits
Model: Impregnated Diamond Core bits
Drilling: Exploration Core Drilling
Drills: Wireline Core Drilling
Mining: Australia mining
Exploration: Australia Exploration
हाई लाइट:

Diamond Core Drilling Bits

,

Diamond Core Drill Bits For Rock

मूलभूत जानकारी
उत्पत्ति के प्लेस: CHINA
ब्रांड नाम: ROSCHEN
प्रमाणन: ISO
मॉडल संख्या: BW NW HW PW
भुगतान & नौवहन नियमों
पैकेजिंग विवरण: Cartons
आपूर्ति की क्षमता: 1000 pcs
उत्पाद विवरण

NW Impregnated hard rock Casing shoe drill bit for Exploration Core Drilling




Casing shoe drill bit


Our impregnated diamond core bits are the most commonly useful bits in the mineral exploration industry, as they have the widest range of application. The carefully selected grades of high quality synthetic diamond are distributed in the depth of impregnated bit's matrix series. The matrix layer of the "ROSCHEN" contains a uniform distribution of these crystal that are embedded in a powdered metal bond.


The matrix of our impregnated bits is designed to expose new diamonds to the bits' cutting face as wear occurs. Fast penetration rate is maintained as a result of this action.




Diamond Drill Bit / Reaming Shell Specification
Item Bit Reamer
Single Pipe Double Pipe Wire pipe Single Pipe Double Pipe Wire pipe
  36 36   36 36
  46 46   46 46
  56 56   56 56
  59 59 59 59 59 59
Specification 75 75 75 75 75 75
    76     76
  77 77 77 77 77 77
  91 91 91 91 91 91
  94 94   94 94
    101     101
  110 110   110 110
  130     130
  150     150
  170     170
  200     200
  220     220
  225     225
  250     250
  275     275
  325     325
      BQ   BQ
      NQ   NQ
      HQ   HQ
      PQ   PQ



Size Available:


Specifications
Q Series AQ, BQ, NQ, NQ2,NQ3,HQ, HQ2,HQ3,PQ,PQ2,PQ3
T, TT, T2&TB Series T36, TT46, T2-46, TB56, TT56, T2-56, T2-66, T2-76, T2-76 Core line, T2-86, T2-86 Core line, T2-101,T2-101Core line
T6 Series T6-76, T6-86, T6-101, T6-116, T6-131, T6-146
B Series (ISO3552-1) B36, B46, B56, B66, B76, B86, B101, B116, B131, B146
WF Series: HWF, PWF, SWF, UWF, ZWF
WT Series: RWT, EWT, AWT, BWT, NWT, HWT (Single Tube/Double Tube)
WG Series: EWG, AWG, BWG, NWG, HWG (Single Tube/Double Tube)
WM Series: EWM, AWM, BWM, NWM
N Guage Core Bits WLN, WLN2, WLN3, NMLC, NWG NX, NWM, NWT, TNW
H Gauge Core Bits WLH, WLH-3.830, WLH-3.895, WLH3, WLHTT, HMLC, HWF-long, HWM,HWT


Type of the bit matrix
The matrix of our impregnated bits is designed to expose new diamonds to the bits' cutting face as wear occurs. Fast penetration rate is maintained as a result of this action, also with long life using time is important, meanwhile it will keep the cost of diamond drilling to a minimum.




The optimum diamond size, concentration and matrix type are dependent on the hardness and abrasiveness of the formation to be drilled.




Earth Feature Rock Name Bit Matrix Type
Soft Mudstone, shale, soft sand, peat, rock, mudstone, tuff, Flat Bottomed Type, Arc-shaped, Steps Shaped Type(PDC non-Coring Drill Bit)
Hard marl, marl and other hard sandy clay
Medium Limestone, marble, dolomite, rhyolite, limonite, etc Steps Shaped Type, Concentric Circles Type, Canine Tooth Shaped Type, Wheeling Gear Shaped Type
Hard Basalt, gneiss, granodiorite, hornfels, pegmatite, diabase,etc Steps Shaped Type, Concentric Circles Type, Canine Tooth Shaped Type,. Wheeling Gear Shaped Type
Solid Hard Hard granite, the British conglomerate, quartzite, hard slate, Steps Shaped Type, Concentric Circles Type, Canine Tooth Shaped Type,. Wheeling Gear Shaped Type
volcanic rocks, chert, basalt, etc









FAQ

Terms & Conditions of Ordering:

Quality warranty:
Our products are made of high quality steel and all spares parts are inspected strictly before shipping. We have quickly responses for your complaint and suggestion.

Package:
Using ply-wooden cases and pallet for package to protect the products and avoid the damage during transportation. Also we can customize package according to your special requests.

Production time:
Generally need 15-25 days

Transportation:
By air, By Express or By sea according to your requests.


1. Methods of Payment:
T/T (Telegraphic Transfer) or Western Union or L/C at sight

2. Handling time for an order
Based on order quantity, normally it takes 20 days for production.
in 3 working days after receiving the advance payment

3. Shipping way
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.

4. Quality Control
We have our own experienced QC.
There will be strict inspection and testing for every order before shipping out.

5. After Services:
a. Our sales team will response for your question within 24 hours (Holidays Excluded)
b. Technical Support will be available in any time

6. Quality & Service:
A. There will be strict inspection and testing for every order before shipping out.
B. Our sales team and Technical Support will response for your question within 24 hours through skype: ROSCHEN.TOOL and WhatsApp/Wechat: +86-13764195009
C. Free replacement will provide once the failure confirmed caused or our product quality; Not satisfied with a refund.
